Feature

Multiple sets of electrode sensors monitor the channel status in real time, make accurate logical judgment, and have no obstacle to authorized passage

Four fold protection for pedestrians in the passage: mechanical device, door position, current detection and passage sensor

The operation of the whole system adopts stepless positioning device, and the operation process is controlled by sensors without mechanical collision.

CNC processing technology, The product surface is finely treated, strong corrosion resistance

It has the function of automatic reset. After the pedestrian reads the valid card, if he does not pass within the specified time, the system will automatically cancel the user’s permission to pass this time.

It is easy to use and convenient for carrying things, such as parcels, luggage, etc.

Anti tailing function: prevention level 2

Traffic mode: one way, two-way (optional), adjustable running speed; multiple working modes available

Light prompt: direction indication

It has the function of lightning protection and leakage protection

Protection function: anti pinch, anti-collision, anti blocking, anti stall, anti over-voltage and over-current of electrical appliances

Prevent illegal operation and alarm function

Standard external electrical interface, with photoelectric safety isolation, can be connected with various control equipment for system integration

Remote control and setting function

Dimensions (mm)

Diameter: 168mm* Height: 1000mm.

Channel Width: 600-900 mm.for 1 unit

Main material

Box: SUS304 2.0mm stainless steel.

Movement: 45 × steel, color zinc plating on the surface.

Swing gate: plexiglass plate.

Movement performance

Swing arm: plexiglass plate, etc.

Drive mode: Servo positioning driver.

Safety mode: automatic opening after power failure.

Power driven: 24v DC brushless motor

Opening and closing speed: 0.2 ~ 0.4s (user can set)

Equipment noise: door opening and closing ≤ 30dB.

Traffic speed: 35 persons / min in normally closed mode; 60 persons / min in normally open mode.

Core life: 8 million times.

Electrical and environment

l Voltage: 100V to 240V AC (large range of power input voltage)

l Frequency: single phase 50Hz to 60Hz

l Working voltage: DC24V

l Current: static 300mA; dynamic 4a (maximum working current)

l operating temperature: - 20 to 70 ° C (- 4 to 158 ° f)

l Storage temperature: - 40 to 80 ° C (- 40 to 176 ° f)

l relative humidity: 5% to 95% in non solidification state

Communication function

Standard RS232 serial port

Digital I/O

RS485 / CAN bus interface (optional)

Installation requirements

Single phase 3A 110V to 220V AC power supply, grounded

Connecting line to control equipment

Possible civil and fixing work

Technical parameter
